12 Years of Homelab Evolution: From Seedbox to 252TB

I’ve been running a homelab for over 12 years now.

What started as a Raspberry Pi running seedbox scripts has evolved into a multi-site infrastructure with 252TB of storage, distributed compilation clusters, and a custom Linux distribution. Along the way, I’ve broken things spectacularly, learned painful lessons, and accidentally built something that actually works.

This is the timeline.

The Eras

Era	Years	Hypervisor	Storage	Network	Defining Moment
Seedbox	2012-2014	None	USB drives	Flat	”It works!”
ESXi	2016-2019	VMware	iSCSI	VLANs	”Why is licensing so expensive?”
Proxmox	2019-2023	Proxmox VE	ZFS/Btrfs	Tailscale	”This is actually free?”
Argo OS	2023-Now	Proxmox + Bare Metal	Distributed	Mesh	”I should build my own distro.”

Era 1: The Seedbox Days (2012-2014)

The Setup:

Raspberry Pi Model B (256MB RAM)
USB 2.0 external drive
rtorrent + rutorrent
OpenVPN to access from work

What I learned: Linux can run on anything. SSH is magic. Automation beats manual work.

The Pi sat in a corner of my apartment, silently downloading. It cost $35 and used 2.5 watts. I could access it from anywhere via a clunky OpenVPN tunnel that dropped every 20 minutes.

It was terrible by modern standards. It was also the start of everything.

The failure that ended this era: The USB drive failed. No backups. Lost everything. The Pi itself was fine—it just had nothing to serve.

Lesson: Storage is not optional.

Era 2: The ESXi Years (2016-2019)

I got serious. Bought actual server hardware.

The Hardware:

Dell PowerEdge R710 (eBay, $400)
32GB ECC RAM
iSCSI SAN (Synology DS1815+)
8x 4TB drives in RAID 6

The Stack:

VMware ESXi 6.5
Windows Server 2016 (AD, DNS, DHCP)
Ubuntu VMs for everything else
VLANs for isolation (management, storage, DMZ)

This was “proper” infrastructure. I learned Active Directory, group policies, proper networking with VLANs, SAN protocols, and enterprise monitoring. I felt like a real sysadmin.

The costs:

vCenter license: $0 (evaluation mode, technically)
Time spent fighting vSphere: Infinite
Electricity bill: +$50/month (that R710 was hungry)

What I learned: Enterprise software is powerful and complex. VLANs are essential for security. SAN storage is rock solid but expensive. Windows Server exists (I don’t miss it).

The failure that ended this era: VMware announced changes to their free tier. The writing was on the wall—ESXi for homelabs was going to get harder. Plus, I was tired of working around licensing restrictions.

Also, the R710’s fans sounded like a jet engine. My wife threatened divorce.

Era 3: The Proxmox Migration (2019-2023)

The Revelation: Everything ESXi did, Proxmox did for free. With better Linux support. And no licensing anxiety.

The Migration:

Week 1: Set up Proxmox test node
Week 2: Migrated non-critical VMs
Week 3: Migrated critical VMs
Week 4: Decommissioned ESXi
Week 5: Sold the R710 on eBay

The New Hardware:

Dell OptiPlex 7050 SFF (silent, 35W idle)
64GB DDR4 RAM
NVMe boot + SATA SSD storage
Same Synology NAS (kept the investment)

The Stack:

Proxmox VE 7.x → 8.x
LXC containers (lighter than VMs)
ZFS for local storage (snapshots!)
Tailscale for networking (goodbye OpenVPN)

The Game Changer: LXC Containers

VMs are heavy. Each one needs its own kernel, its own memory reservation, its own disk image.

LXC containers share the host kernel. They’re lighter, faster, and use less resources. For Linux workloads, they’re almost always the right choice.

Workload	VM	LXC	Winner
File server	2GB RAM	256MB RAM	LXC
Docker host	4GB RAM	1GB RAM	LXC
Windows	Required	N/A	VM
Untrusted code	Safer	Risky	VM

I went from running 8 VMs to running 3 VMs + 15 LXC containers. Same hardware. More services.

What I learned: Open source wins. Containers beat VMs for most workloads. ZFS snapshots are life-saving. Tailscale is magic.

The failure that almost killed me: A Proxmox upgrade broke ZFS. 16 hours of recovery. I now test upgrades in a VM first.

Era 4: The Argo OS Era (2023-Present)

At some point, “homelab” became “distributed infrastructure.”

The Current Inventory:

Hypervisors

Host	Hardware	Role	Location
Arcturus-Prime	Dell OptiPlex 7050	Primary Proxmox	Local
Altair-Link	Dell OptiPlex 7040	Secondary Proxmox	Local
Tarn-Host	HP ProDesk 600	Remote Proxmox	Remote site

Storage

Device	Capacity	Type	Role
Synology DS1821+	64TB raw	NAS	Local backup, media
Unraid (Meridian-Mako-Silo)	120TB raw	NAS	Remote archive, Plex
Synology DS920+	32TB raw	NAS	Remote backup
Various NVMe	~6TB	Direct	VM storage

Total usable storage: ~252TB

Compute

Machine	CPU	RAM	Role
Canopus-Outpost	i7-4790K	32GB	Daily driver (Argo OS)
Tau-Ceti-Lab	i7-4771	32GB	Build drone, testing
Various VMs	-	~128GB total	Services

Network

The mesh: Tailscale connects everything. Local is 10.42.0.0/24. Remote is 192.168.x.0/24. Tailscale makes them feel like one network.

Key services:

Subnet routing from LXC containers
Exit nodes for mobile devices
ACLs for access control
Auto-approvers for route advertisement

Why Tailscale? I spent 16 months fighting port forwarding, dynamic DNS, and VPN tunnels that dropped. Tailscale just works. 38ms latency to remote sites. No holes in my firewall.

The Storage Philosophy

After losing data twice (USB drive in 2014, Proxmox ZFS scare in 2021), I’m paranoid about storage.

The 3-2-1 Rule

3 copies of important data
2 different storage types
1 offsite

Implementation:

Primary: Local NAS (Synology, RAID/SHR)
Secondary: Remote NAS (replicated overnight)
Tertiary: Cloud (encrypted, rclone to Google Drive)

Filesystem Choices

Use Case	Filesystem	Why
Proxmox VM storage	ZFS	Snapshots, compression, reliability
NAS arrays	Btrfs/ext4 on Synology	It’s what Synology uses
Unraid	XFS + parity	Unraid architecture
Desktop (Argo OS)	Btrfs	Snapshots for rollback

The Upgrade Cycle

I buy used enterprise drives. 8TB HGST drives are $40-60 on eBay. They have SMART data you can check, and they’ve survived a datacenter burn-in.

My rule: If a drive has >50,000 power-on hours, I only use it for non-critical data. If it has reallocated sectors, I don’t use it at all.

The Compilation Problem

This is where Argo OS was born.

I run Gentoo on my desktop. Gentoo compiles everything from source. A full system update can take 48 hours on an i7-4790K.

The solution: Don’t compile on the desktop. Compile on everything else.

The Build Swarm

Drone	Cores	Location	Role
drone-Izar	16	Local VM	Primary
drone-Tarn	14	Remote VM	Secondary
dr-mm2	24	Docker on Unraid	Heavy lifter
Tau-Ceti-Lab	8	Bare metal Tau-Ceti-Lab	Backup

Total: 62 cores for parallel compilation.

How it works:

Orchestrator receives package list
Distributes packages to drones based on availability
Drones compile and upload binary packages
My desktop downloads binaries instead of compiling

Result: Firefox update went from 45 minutes (compile) to 30 seconds (binary install).

The Lessons (Chronological)

2012: Backups Are Not Optional

Lost a USB drive. Lost everything on it. Never again.

2014: Redundancy Means Something

RAID is not backup. But RAID protects against drive failure. Both are necessary.

2016: Enterprise Gear Is Loud

The R710 was powerful. It was also 80dB at idle. Your family will complain.

2017: VLANs Are Essential

Without network segmentation, one compromised device can access everything. VLANs fixed that.

2018: Licensing Is a Trap

Free tiers disappear. Evaluation modes expire. Open source is forever.

2019: Containers Beat VMs

For Linux workloads, LXC uses 1/4 the resources of a full VM. Docker on LXC uses even less.

2020: Tailscale Changes Everything

16 months of VPN pain erased in one afternoon. Mesh networking is the future.

2021: Test Your Backups

I had backups. I’d never tested restoring them. The Proxmox ZFS scare taught me: an untested backup is not a backup.

2022: Snapshots Are Undo Buttons

Btrfs snapshots on my desktop mean I can break anything and rollback in 2 minutes. This changes how aggressively I can experiment.

2023: Compile Once, Deploy Everywhere

Building a binhost means I never compile the same package twice. 62 cores working while I sleep.

2024: Your Distro Is Yours

Argo OS exists because I wanted exactly the system I have. Not Ubuntu’s choices. Not Arch’s choices. Mine.

The Current Architecture

┌─────────────────────────────────────────────────────────────┐
│                      TAILSCALE MESH                         │
├─────────────────────────────────────────────────────────────┤
│                                                             │
│  LOCAL (Milky Way)              REMOTE (Andromeda)          │
│  10.42.0.0/24                   192.168.x.0/24              │
│                                                             │
│  ┌─────────────────┐           ┌─────────────────┐          │
│  │ Arcturus-Prime  │           │ Tarn-Host    │          │
│  │ Proxmox         │           │ Proxmox         │          │
│  │ 15 containers   │           │ 8 containers    │          │
│  └────────┬────────┘           └────────┬────────┘          │
│           │                             │                   │
│  ┌────────┴────────┐           ┌────────┴────────┐          │
│  │ Rigel-Silo      │           │ Meridian-Mako-Silo     │          │
│  │ Synology 64TB   │           │ Unraid 120TB    │          │
│  └─────────────────┘           └─────────────────┘          │
│                                                             │
│  ┌─────────────────┐           ┌─────────────────┐          │
│  │ Canopus-Outpost │           │ Cassiel-Silo       │          │
│  │ Argo OS Desktop │           │ Synology 32TB   │          │
│  └─────────────────┘           └─────────────────┘          │
│                                                             │
│  ┌─────────────────┐                                        │
│  │ Tau-Ceti-Lab    │                                        │
│  │ Build drone     │                                        │
│  └─────────────────┘                                        │
│                                                             │
└─────────────────────────────────────────────────────────────┘

The Cost Analysis

Initial Investment (2016-2019 ESXi era):

R710: $400
RAM upgrades: $150
Drives: $800
Synology: $800
Total: ~$2,150

Current Investment (2019-present):

OptiPlex 7050: $200 (used)
OptiPlex 7040: $150 (used)
Various RAM: $300
Drives (accumulated): ~$2,000
Synology additions: $500
Unraid license: $130
Remote Synology: $600
Total: ~$3,880

Running costs:

Electricity: ~$30/month (down from $80 with the R710)
Tailscale: Free tier
Google Drive (backup): $10/month
Internet: Already paying for it

Total 12-year investment: ~$6,000 + ~$4,000 in electricity = $10,000

What I got:

252TB of redundant storage
Distributed compilation cluster
Custom Linux distribution
Skills that got me promoted twice
A hobby that never gets boring

Worth it.

What’s Next?

Short term:

Finish Argo OS Part 5 (the apkg package manager)
Upgrade to 10GbE between local nodes
Add a dedicated GPU node for AI workloads

Long term:

Kubernetes? Maybe. LXC works well enough.
More remote sites (family members want in)
Better monitoring (Prometheus/Grafana stack)

Never:

Going back to Windows Server
Paying for VMware
Running without snapshots

The Philosophy

A homelab is a sandbox. It’s where you break things safely. It’s where you learn by doing.

Twelve years ago, I just wanted to download things faster. Now I’m running a custom Linux distribution across multiple sites with distributed compilation and mesh networking.

The path wasn’t planned. Each problem led to a solution that created new problems. That’s the fun.

If you’re starting out: begin small. A Raspberry Pi. A used OptiPlex. One external drive. You don’t need 252TB on day one.

The lab grows with you.
